HotShock 5 (Plug-In) Energizer Kit
- Peak output: 0.5 joules
- Pulses per minute: 38
- 110 AC draw: 1 watt per hour
- 12v DC draw: 46 mA/hr. With this energizer a 12v 100 ampere hour, deep cycle battery will last approximately 54 days* on a clean or a weedy fence. *Assumes being drawn down to 40% between recharges.
- Includes: 12v battery leads and 110v adapter
- Impedance type: low
- Should power 1 mile of 3 strand cattle fence, 1/2 mile of a 5-7 strand sheep fence, 6 of the 164' sheep/goat nets and 3 of the 164' poultry nets. All distances are dependent on amount of grass/weed load on the fence.
- HotShock 5 Energizer
- 100 ft insulated wire
- 3 ft ground rod
- 5-light fence tester
5-Light Tester: Low cost way to make sure you have enough volts on the fence to keep animals in and predators out.
Ground rod and clamp: Galvanized rod does not rust or corrode.
100 ft MaxiShock Single ins. Cable: It's extra-thick layer of galvanized zinc will protect the connection from rusting for years. Unlike normal insulated fence wire, MaxiShock insulated cable does not require special connectors.
How to Use
The HotShock 5 can be mounted either inside or outside of a building, but not where there is risk of fire. The energizer must be mounted vertically. Protect the energizer from direct rainfall or flooding.
- Connect insulated cable (stripped back 1 - 2" on ends) to the fence terminal on energizer, run the cable to the fence line and connect, or use the positive part of the Wiring Harness, not included.
- Then run a second length of cable from the ground terminal (with ends stripped again) on the energizer to the ground rod, or use the negative part of the Wiring Harness, not included.
- Secure to ground rod with a clamp.
- Plug into outlet and test fence.
- For Fence:
- Insert the probe of the tester into the soil.
- Remove your hand from the metal portion of the probe (to avoid a shock).
- To get a voltage reading, touch the metal clip (on the top of the tester) to the electrified fence you wish to test.
- The tester will light up according to the voltage at that location on the fence.
- Remove the tester from the fence and the probe from the soil. Do not remove the probe by pulling the insulated wire.
- For Energizer:
- Turn off energizer.
- Disconnect ground wire and fence wire from energizer.
- Turn on energizer.
- Touch probe from tester to ground terminal on energizer (be sure to hold onto the insulated wire and not the metal probe!)
- At same time touch the fence hook on tester to fence terminal on energizer.
- The tester should light up to 6000 volts or more.
Ground rod and clamp
- Allow 3 ft of rod per joule of energy released.
- Use multiple 6 ft rods for large energizers and 3 ft rods for smaller energizers (and lightning diverters).
- Make sure to put the ground rod all the way into the ground.
- To attach ground wire, strip the coating off the wire 1" - 2" and make an elongated "U" in the wire.
- Put the "U" against the rod and put the clamp around it. Tighten.
100 ft MaxiShock Single ins. Cable:
Just cut the soft wire cable with a knife, strip off the insulation and wrap it 4 or more times around the wire by hand. It can be removed and reinstalled many times
- Make sure the energizer is unplugged before working on the fence or the energizer.
- When using a 12v deep cycle battery, there is no case to protect the battery, so the battery will be exposed to the elements and risk of theft.
Ground rod and clamp: When installing more than one ground rod, space the ground rods apart 2 feet longer than the rod. Example 3' rods should be spaced 5' apart.
To determine if the fault is with the fence or the energizer...
- Test the energizer first
- Turn off energizer.
- Disconnect ground wire and the fence wire.
- Turn energizer back on.
- With fence tester, put the ground probe (or clamp) to the ground terminal on the energizer and the metal loop (or positive clamp) at the top of the tester to the fence/positive terminal. The reading you get tells you how well the energizer is working without any other variables. If there is a very low voltage (under 4000v) or no voltage, then the energizer may have a problem. If the voltage is high (greater than 4000v) then the trouble lies with your fence. Most energizers put out between 5000v and 8000v when there is no load (i.e. no fence hooked up).
- Check that the 110v outlet is "live" by using a plug-in drill or test light.
- If the test light works and the energizer does not, call Premier.
If the energizer is faulty and you are using it as a battery unit you need to learn if the battery or the energizer is the problem…
- If it's a 12 volt energizer carry the unit to a nearby vehicle and attach the input cords carefully to the vehicle's battery.
- If the energizer now works, then your fencer's battery needs to be recharged or replaced.
- If the energizer does not work, then you should call Premier re. repairs.
If the fence is at fault, then you must find the fault(s) and fix them. Here's how to start this process:
If you have a Fault Finder you can simply touch the fence with the Fault Finder at various points along the electric fence(s). The Fault Finder will tell you at each point which direction to go in to locate the problem. Move in that direction testing as you go and you will arrive at the problem.
If you lack a Fault Finder…
- Walk or drive along the fence looking for any point in which the energized wires touch the soil, a steel post or a steel wire. On HT wire fences, check the wires at braces to see if they are touching a hot wire. On netting, look for a hot wire touching the metal stake at the bottom of the plastic posts. Also look for damaged insulators.
- If the fence can be separated into several parts (by switches or by disconnecting parts of it), you can locate the problem by beginning at the far end and then progressively turn off or disconnect the sections of fence. When the voltage on the remaining fence rises sharply, you've located the section(s) that's causing the problems.
- The alternative to (2.) is to begin at the fencer and progressively turn on sections of the fence. When the voltage suddenly drops you can assume that the problem is in the section most recently connected.
- Make sure that the probe has not become separated from the black insulated wire.
- Cup your hands around the body of the tester to keep the sun's glare off the lights of the tester.
Ground Rod and Clamp:
If you are not getting a good reading on your fence:
- Make sure to have the ground rod all the way into the ground
- Make sure you have a good connection to the ground rod
- Make sure to have a good connection on the energizer and fence
When you buy an energizer from Premier, you purchase more than an energizer. You obtain these benefits:
- If an energizer fails within 2 years of its date of purchase, we will replace the failed module or unit at our cost. Your credit card will be charged for the replacement but you will receive full credit when the failed item is back at Premier. Your only cost is shipping the failed item to us. If the original energizer is over 2 years old, we will repair it, but you pay for the repair cost and freight.
- Free next-day air shipment of warranty replacement energizers. A unit can be shipped by 11 a.m. Central Time to be received the next day. (Calls on Friday after 11 a.m. will ship Monday.)
- Free technical support. We provide free advice before you purchase an energizer and free support afterwards for as long as you wish. This applies to energizer repair issues as well. If you are not sure how to replace/repair a module, we will “walk” you step-by-step through the process over the telephone.
- Solar energizer packages. With larger energizers (over 1 joule), the panel, battery and energizer need to be correctly sized for each situation. Call us and talk to our consultants.
- Five-year assurance against energizer obsolescence. Premier’s “contract” with our customers includes repair or replacement of any nonworking units for up to 5 years whether the unit is “obsolete” or not. During the 2-year warranty period, Premier pays for the replacement cost.
Note: Policy does not apply to failure due to abuse or neglect.
Warranty does not cover batteries.
If you think your energizer has failed, call us at 1-800-282-6631. We’ll help you test your energizer to ensure that it has truly failed. This is important because we’ve found that 25% of the units returned to us work fine. The fence was at fault, not the energizer.
Listed below are recommended optional components or related items. Your particular situation may require alternative recommendations. Please call and talk to our consultants if there are any questions at 800-282-6631.
Electric NettingItem #201930 -
We've simplified the process and taken the "guess" work out by offering kits to complete your poultry fence system. You will need a PoultryNet kit and an Energizer kit (see accessories below).$176.00
